Connection channel between the inner and outer socket shell. • Available in 16mm or 21mm diameters • Beige or black color options

Used to connect the electrodes in myoelectric systems to a:9E169 Coaxial Plug13E205 MyoRotronic9E369/9E370 4-in -1 LS Controller or 9E420 7-in-1 Controller13E190 Distributor or 10S7 Electric Wrist Rotator

Lamination ring for System Electric Hands or System Electric Greifers with lamination protection cover for bonding.

The MyoRotronic is compatible with all ottobock Myobock System Electric Hands and System Electric Greifers with Quick-Disconnect Wrist and enables proportional or digital control of the 10S17 Electric Wrist Rotator.5 different programs can be selected using the 757T13 Myo Select and allow individual adaptation to the respective patient. One or two 13E200 Electrodes or 13E202 Suction Socket Electrodes or a combination of one electrode and a 9X50/9X52 Linear Control Element are used to control the 13E205 MyoRotronic.Includes:MyoRotronic13E183 Buzzer for acoustic feedback on the switchoverThe 757T13 MyoSelect is required to select programs and adjust the 13E205 MyoRotronic. When using the 10S17 Electric Wrist Rotator and the 13E205 MyoRotronic, the distance between the residual limb end and wrist must be at least 65 mm . The rotation can be switched off using the 9X24 Connection Cable.

The Electric Wrist Rotator provides electrical rotation that can be operated with all ottbock System Electric Hands that are equipped with the Quick Disconnect Wrist.Required for pronation and supination of the handIf muscular tension is not sufficient for operation with the 13E205 MyoRotonic, the 10S17 can be controlled by the 9X14 Harness Pull Switch, the 9X18 Traction Switch, or the 9X25 Rocker SwitchIncludes:11S4 Lock Ring11S61 Wrist Drive with Coaxial Plug11S25 Lock Ring9E85 Protective Cap9E363 Drive Unit9E365 Protection Plug

For connecting the two electrodes and battery.

Includes: Coupling Piece 11S4 Lock Ring

The MyoSkin Natural Glove for Women has a multi-layered design providing depth and a very vivid, natural appearance. Robust and easy to clean, the glove protects the prosthesis from dust, dirt and moisture.MyoSkin Natural Gloves are especially designed for Myobock hands.Multilayered structure provides natural appearance and resilient prosthetic coveringDirt can be removed with water and soap, while tough stains can be cleaned with the 640F12 Ottobock Special CleanerManufactured in seven colors (2, 4, 6, 8, 11, 14, 16); Use 646M47 color scale for selectionMulti-Layered PVC provides depth effect for vivid, natural appearanceOuter translucent layer allows colored fibers to shine through producing luminous qualityTreated with a special surface treatment for easy clean-upNail polish can be applied and reapplied to the finger nails and removed with acetone-free nail polish remover.

The 13E200 Myobock Electrode lessens sensitivity to low and high frequency interferences to minimize prostheses operation interruption and provide noise filtration.

Electrode cable connection with IDC termination, with 13E206 Electrode Accessories, without electrode cable. Creates an airtight seal between the inner socket and outer socket when embedded into a mounting suspension of elastic material. The Suction Socket Electrode also prevents sweat from penetrating between the outer and inner socket, preventing damage to the electrical and mechanical components caused by corrosion.The Suction Socket Electrode can not only be used for standard fittings, but is also suitable for application in suction sockets. Combining the suction socket electrode with a 12V10 Tube Valve for a suction socket creates a vacuum effect in the socket, ensuring optimal linkage between the residual limb and the socket.Shielding and filtering technologies largely protect the 13E202 Suction Socket Electrode against high frequency interference caused by cell phones, walkie-talkies, computers or anti-theft systems in shopping centers so that the correct function of the myoelectrically controlled prosthesis is not affected. The electrode contacts are made from pure titanium and are suitable for people with allergies.Includes:(1) 13E200 electrode(1) 13E80 adjustment tool(1) 13E191 casting template for inner socket(1) 13E192 lamination template(2) 507S15 lamination plate with bore(1) 13E201 electrode accessories for vacuum-formed inner sockets(2) 503F3 socket screw with Allen headThe following products are also required:13E129=* electrode cable
