3R93 Modular Brake Knee with Lock
Quick Links
| Part # | Description |
|---|
Product Information
The 3R93 Modular Brake Knee features a load-dependent brake mechanism and an optional locking function. It has an integrated, adjustable extension assist springs that control the swing phase.
- Braking and stance flexion action can be easily adjusted
- User pulls on a cable to release the joint
- Not suitable for bilateral transfemoral amputees
- Includes 710H10=2X3 Adjustment Wrench and 4F18=N Lock Slide, Complete
Specifications
- Activity Level: K1, K2
- Knee Design Type: Single Axis, Friction Swing and Stance Phase Control
- Axis: Single Axis
- Swing Phase: Friction
- Stance Phase: Friction
- Control Frame Material: Aluminum
- Product Weight (g): 760
- Maximum User Weight: 275lbs (125kg)
- Maximum Knee Flexion Angle: 130 Degrees
- Proximal Connection: Pyramid Adapter
- Distal Connection: Tube Clamp
- Trial Period: N/A
- Warranty: 24 months from delivery date
