3R106 Modular Knee Joint, Servo-Pneumatic
Quick Links
| Part # | Description |
|---|
Product Information
The 3R106 Modular Knee features a dual-chamber pneumatic unit with progressive damping properties has a flexion valve that the prosthetist sets for the user’s normal walking speed. The flexion resistance increases auto-adaptively, preventing too much flexion of the knee joint when walking at faster speeds.
- Pendulum movements in the swing phase
- Accommodates patients with longer residual limbs
- Supports a wide range of walking speeds
- Durable, robust, and smooth-running needle roller bearings technology
- Includes 513D83=1.4X12.6X66 Compression Spring, Heavy duty and 513D83=1.1X12.9X66 Compression Spring, light duty
Specifications
- Activity Level: K2, K3
- Knee Design Type: Multi-Axial 4-Bar Linkage, Pneumatic Swing Control
- Axis: Polycentric
- Swing Phase: Pneumatic
- Stance Phase: Friction
- Control Frame Material: Aluminum
- Product Weight (g): 870-910
- Maximum User Weight: 275lbs (125kg)
- Maximum Knee Flexion Angle: 175 Degrees
- Proximal Connection: Refer to chart below
- Distal Connection: Tube Clamp
- Trial Period: N/A
- Warranty: 24 months from delivery date
